| TYPE | DESCRIPTION |
| Mfr | Nexperia |
| Series | - |
| Package | Tape & Reel (TR) |
| Product Status | ACTIVE |
| Tolerance | ±2% |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Mounting Type | Surface Mount |
| Operating Temperature | 150°C (TJ) |
| Voltage - Zener (Nom) (Vz) | 22 V |
| Impedance (Max) (Zzt) | 55 Ohms |
| Supplier Device Package | TO-236AB |
| Grade | Automotive |
| Power - Max | 250 mW |
| Voltage - Forward (Vf) (Max) @ If | 900 mV @ 10 mA |
| Current - Reverse Leakage @ Vr | 50 nA @ 15.4 V |
| Qualification | AEC-Q101 |
